30'x50' High Peak tents for sale from Ohenry Tents, commercial tents for the high peak tent rental and party tent rental industry
30'x50' High Peak tents for sale by Ohenry are made for the abuse of the party tent rental industry. Ohenry has High Peak tents for sale which are built with top quality American made vinyl. Ohenry High Peak tents are kept in stock! Heavy duty commercial tents which are designed for tent rentals.

30x50 Ohenry High Peak Pole tent

Ohenry 30x50 High peak tents are classified as "tension" tents. They are highly portable like a traditional pole type tent, and because of aerodynamic design highly resistant to extreme winds.

High peak tents are extremely desirable for weddings, and other events where an elegant look is desired. While more expensive, the high peak commands admiration.

  • Picture
  • Description
  • What's Included
  • Pole Tent Vs. Frame Tent
  • Instructions and Drawings
  • Compare Ohenry Quality
  • Warranty & Policies

Mystique High Peak Tension Tent 30’x 50’
Ohenry “high peak tents” are classified as "tension tents". They are highly portable like a traditional pole type tent, and because of aerodynamic design highly resistant to extreme winds. High peak tents are an ideal solution where the is expected to be . With the high resistance to wind, and exceptional drainage due to the steep pitch, a high peak design presents many desirable advantages over traditional pole type tents, or frame tents . All Ohenry products comply with the California Fire Marshall's Office flame resistance requirements.

Top & hardware kit (no walls).

Kit includes:

tent top, 20-side poles, 2-21' center pole, 24-42" stakes and 24-2” ratchet straps

Shipping weight = 892 LBS (excluding sidewalls)

See the superior Ohenry manufacturing process:





Content on this page requires a newer version of Adobe Flash Player.

Get Adobe Flash player


Which is best, a frame tent or a pole tent?

If you are considering purchasing a frame tent, there are a few things we would like to make you aware of so you can wisely choose between a frame tent and a pole tent.

  1. Frame tents are normally more expensive than pole tents.
  2. A pole tent is much more portable than a frame tent.
  3. Pole tents are much easier to install than a frame tent.
  4. Typical installation time for a 20x30 frame tent = 4- men 1.5 hours
  5. Typical installation time for a 20x30 pole tent = 2-men 20 minutes
  6. Typical installation time for a 40x80 frame tent = 10 men 6-7 hours
  7. Typical installation time for a 40x80 pole tent = 2 men 1.5 hours
  8. Frame tents are NOT "Free Standing" as sometimes advertised.  They must be staked out just like a pole or tension structure must be. The only exception is for indoor use.
  9. Pole tents will withstand higher wind loads than a frame tent.
  10. The hardware on a frame tent is very specialized, including pieces which are either cast aluminum, or welded steel. If you lose or damage one of these pieces, your frame tent is useless until you can find a replacement part from the manufacturer.
  11. The hardware on a pole tent (poles & stakes) is made of  items which in a pinch you can find suitable replacement materials at any building material supply company.  Rebar can be substituted for stakes, and a 2"x 4" with a large nail inserted in one end can substitute for a side pole.
  12. Finally, the hardware on a frame tent is SIZE SPECIFIC.  In other words, if you own a frame 20x20 and a 30x30, the parts do not interchange.  You can imagine how frustrating all this can be when you are dealing with an expensive frame tent!
  13. Frame tents do have some advantages for certain situations which do not allow complete staking.

Installation Manual

Seating drawing for Auditorium

Seating drawing for Tables and chairs





Approved vendor to the U.S. Army, Air Force & FEMA!
  • Ohenry tents are built for commercial, and industrial use. We build all our tents to endure multiple set ups and takedowns. Ohenry tents are specifically designed to endure the daily abuse of a rental environment. For 25 years we had a tent rental division, and we know first hand the abuse a rental tent can be subjected to.
  • All Ohenry tents are constructed with 100% American made products when possible. We refuse to use inferior and less expensive tent material, rope, webbings or hardware. A tent using inferior components will cost 60% less to manufacture, but simply will not last.
  • Please examine closely the perimeter "edge work" as well as the lace lines, corner fittings, center pole fittings and side pole fittings of any tent you are contemplating for purchase, regardless of the manufacturer. These are the areas where shortcuts are made to reduce cost of manufacturing. However, these are the most critical areas of tent construction, and any shortcuts made here will simply guarantee that the tent will not last as it should!
  • When you buy an Ohenry tent, you know the fabric is first run (no seconds) quality material. Our side walls are also constructed of 13 - 14 oz material. We do not use the inferior 10 oz material common to many manufacturers.
Important specifications
Ohenry
Other manufacturers
  • Weight of tent top material
  • Weight of side wall material
  • Size of "guy out" ropes
  • Type of webbing used
  • Reinforcing at stress points
  • Webbing on entire perimeter
  • Width of welded seams
  • Distance between Side poles
  • Size of  ratchet system
  • 14 -15 oz  standard
  • 13 - 14 oz  standard
  • 1/2" - 5/8"
  • 1.5"-2"  3,000 lb - 6,000 lb test
  • Double & triple thickness
  • 2" seatbelt type
  • 2" first seam, and re-welded with 2.5" strip
  • 30' Wide tents & larger every 5' standard
  • 2" long handle  12,000 lb test
    • 10- 13 oz  standard
    • 8 - 10 oz
    • 1/2" all sizes
    • 1" to1.5" 800 lb test
    • single - double thickness
    • 1" light duty
    • 1/2" - 1" single weld
    • 7.5 '- 10' apart
    • 1.5" short handle 800 lb

    10'x10' --- 20'x40' pole tents
    • Tops constructed of solid white Block-out  13 oz or with a 14 oz translucent color combination ( vertical stripes )
    30' wide...to 70' wide pole tents
    • Tops constructed of solid white Block-out  15 oz.
    • Tops constructed of Block-out white 15 oz with a 14 oz translucent color combination ( vertical stripes )
    80' & 100' wide pole tents
    • Tops constructed of solid white Block-out  15 oz.
    • Tops constructed of Block-out white 15 oz with a 14 oz translucent color combination ( vertical stripes )
    20'x20' - 20'x40' High Peaks
    • Tops constructed of solid white Block-out  15 oz
    • Tops constructed of Block-out white 15 oz with a 14 oz translucent color horizontal stripe
    30'x30' & 30'x50' 1pc - High Peaks
    • Tops constructed of solid white Block-out  15 oz
    • Tops constructed of Block-out white 15 oz with a 14 oz translucent color horizontal  stripe
    30' & 40' wide sectional High Peaks
    • Tops constructed of solid white Block-out  15 oz
    • Tops constructed of Block-out white 15 oz with a 14 oz translucent color combination ( vertical stripes )
    60' wide twin pole High Peaks
    • Tops constructed of solid white Block-out  15 oz.
    • Tops constructed of Block-out white 15 oz with a 14 oz translucent color combination ( vertical stripes )
    Frame tents
    • Tops constructed of solid white Block-out  17 oz.
    • Tops constructed of Block-out white 17 oz with a 14 oz translucent color combination ( vertical stripes )
    Side Walls   *** Standard tent walls are constructed of    Block-out white, translucent white, & colors 13 - 14 oz



    Warranty & Policies



    Click on these other Sizes of Ohenry High Peak Tents for more info:



    Why Ohenry? Video

    Sectional Pole Tent Installation Video

     Lace Line Video

     Side Wall Installation Video

    If you are in the party rental or party tent rental business, you will find Ohenry is your best choice for a heavy duty tent which is designed specifically for the tent rental and party rental industry.  Ohenry tents are built to last many years, and best of all, our tents are in stock waiting for you.  You will never have to wait for your tent. We have all sizes of pole tents, frame tents, and high peak tents in stock, ready to go to work as party tents for you!
